Pass-Through Slat Wood Walls
Pass-Through Slat Wood Walls
UE's Pass-Through Slat Wood Walls are fully customizable, with a range of wood species, finish options, slat sizes, and spacing available for every project.
Key Features
- Available in white oak, walnut, ash, and paint grade, with multiple standard and custom finish options
- Companion veneer and solid trim available for a coordinated look
- Slats sized 1½" x 3½", with 1½" spacing between slats
- Panel supplied 2' or 4' standard width; 8' standard height, up to 10' available
- Minimum order 100 SF
- Prefinished (clear, stain, or paint grade), or available unfinished
- Made in the USA
- Certified Clean Air GOLD and Declare Red List Free
- FSC-certified wood available on request (FSC License Code FSC-C199866)
- Manufactured with solid wood and MDF that exceed the Eco-Certified Composites Standard
- Panels can be reused in their entirety through the UE Takeback Reuse Program
All center vertical slats are located with dowels and screws from the top and bottom of each wall section; the top and bottom horizontal chords attach to the vertical side pieces via dowels, biscuits, and/or pocket screws. Walls small enough (4' x 10' maximum) can be preassembled at the factory and shipped whole. Wood is a natural material that varies in color, grain pattern, texture and overall appearance from piece to piece.
Class A fire-rated finish may be applied on request. Wood's fire rating is dependent on species, application, and finish. Please consult the American Wood Council's Flame Spread Performance sheet for more information.
- Slat Dimensions
- 1 ½" x 3 ½", 1 ½" spacing between slats
- Panel Width
- 2' Or 4' Standard
- Panel Height
- 8' standard, up to 10' available
- Minimum
- 100Sf
- Finish
- Unfinished, Prefinished (Clear, Stain Or Paint Grade)
LEED®:
- Materials & Resources
-
- Material Ingredients – Declare Label
-
- Sourcing of Raw Materials – Wood Products
-
-
- FSC® certified wood can be supplied on request through FSC License Code (FSC-C199866)– please reach out for availability.
-
-
- Sourcing of Raw Materials – Extended Producer Responsibility
- Indoor Environmental Quality
-
- Low-emitting Materials – VOC Emissions Evaluation
-
- Low-Emitting Materials – Formaldehyde Emissions Evaluation (MDF)
Human Health:
- Certified Clean Air GOLD (CDPH Compliant)
- Declare Red List Free
- Low/no VOC finishes available
Source:
- Domestic Timber (Midwest)
- FSC® certified wood available on request
End of Life:
- Panels can be reused in their entirety. Learn more through our UE Takeback Reuse Program
Wood is a natural material that varies in color, grain pattern, texture, and overall appearance. Wood characteristics can be expected to vary from piece to piece.
GRADE: Standard panels use plain sawn select & better veneer and solid wood. Rift sawn veneer and solid wood available on request.
CUSTOM: Panel size, slat size and spacing, and finish may be customized. Please reach out for availability.
